Fly-SUB-15
Powered subwoofer
Fly-Sub-15 is a double 15’’ subwoofer for the Fly-6 line array, designed for low-end support for the entire system. With two high-excursion 15’’woofers and built-in Powersoft modules, Fly-Sub-15 delivers 137 dB of sound pressure, extending from 45 to 200 Hz.
Main features:
- Components: Two 15” woofers with 4” voice coil
- Amplifier power: 2000 W
- Frequency response: 45 Hz – 200 Hz
- Max SPL (calculated): 137 dB
- Mounting: Two M20 distance pole adapters; Fly array U-bracket adapter
With thoroughly designed hardware, Fly-Sub-15 can be easily set up, adjusting to any configuration required.
Fly-6L is reinforced by a comprehensive range of subwoofers: dual 12-inch flyable Fly Sub 12, versatile dual 15-inch Fly Sub 15, and ultimate dual 18-inch Fly Sub 18.
Technical data
| Main | Parametr |
|---|---|
| Type | Powered subwoofer |
| Acoustical & Electrical data | Parametr |
| Frequency response (-10dB) | 45 Hz – 200 Hz |
| Max SPL (calculated) | 137 dB |
| Amplifier power | 2 000 W |
| Amplifier | Class D with DSP, passive cooling |
| Input sensitivity | +4 dBV |
| Settings | 4 switchable presets |
| Connections and physical data | Parametr |
| Connectors | Powercon mains in, Powercon mains out, XLR input, XLR output |
| Dimensions (W x H x D) | 506 х 860 х 578 mm; 19.9" x 33.9" x 22.8" |
| Net weight | 59 kg; 130 lbs |
| Shipping weight | 63 kg; 138.9 lbs |
| Mounting | Fly array U-bracket adapter, Two M20 distance pole adapter |
| Enclosure material | Polycomp©, wear-resistant paint |
| Speaker protection | Steel grill, acoustically transparent backing |
| Color | Black |
