CLUSTER S15
Installation subwoofer
Cluster S15 is an Installation subwoofer, created to provide low-frequency support to the Cluster series. Designed based on a 15” driver of own design and production, Cluster S15 delivers 136 db of sound pressure, with frequency range extending from 37 to 300 Hz.
Main features:
- Components: 15” woofer with 4” voice coil
- Nominal power: 1000 W
- Frequency response: 37 Hz – 300 Hz
- Max SPL: 136 dB
- Mounting: Integrated rigging hardware
Technical data
| Main | Parametr |
|---|---|
| Type | Installation subwoofer |
| Acoustical & Electrical data | Parametr |
| Frequency response (-10dB) | 37 Hz – 300 Hz |
| Max SPL | 136 dB |
| Sensitivity (1W/1m) | 97 dB |
| LF Driver | 15", 4" VC |
| Impedance | 8 Ohm |
| Nominal power | 1 000 W |
| Connections and physical data | Parametr |
| Connectors | 2 x Neutrik Speakon |
| Dimensions (W x H x D) | 480 x 505 x 646 mm; 18.9" x 19.8" x 25.4" |
| Net weight | 38 kg; 83.8 lbs |
| Shipping weight | 41 kg; 90.4 lbs |
| Mounting | Integrated rigging hardware |
| Enclosure material | Polycomp©, wear-resistant paint |
| Speaker protection | Steel grill, acoustically transparent backing |
| Color | Black, White |
